Curtain UV Coating Machine Convenient Paint Thickness Adjustment With Movable Head

I'm Online Chat Now

Curtain UV Coating Machine Convenient Paint Thickness Adjustment With Movable Head

Curtain UV Coating Machine Convenient Paint Thickness Adjustment With Movable Head
Curtain UV Coating Machine Convenient Paint Thickness Adjustment With Movable Head

Large Image :  Curtain UV Coating Machine Convenient Paint Thickness Adjustment With Movable Head

Product Details:
Place of Origin: Jiangsu
Brand Name: JINGZHI
Certification: CE
Model Number: JZ-600# JZ-1000# JZ-1300#
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $12,500.00 - $26,500.00 / Set
Packaging Details: standard shipment
Delivery Time: 30-35 working day
Payment Terms: T/T
Supply Ability: 50sets/month
Detailed Product Description
Model: JZ-600# JZ-1000# JZ-1300# Product Name: Wood Coating Machine
Certification: CE Advantage: High Speed
High Light:

hot melt coating machine

,

automatic coating machine

coater machine and parts for curtain coater, curtain coating equipment



1. This machine is avalible to the surface paint coating like mirror for the furnitureflooringcabinetwallingdecorative boards, which different materials as woodMDFplasticmetalglassCaSi and soon.

2. Convenient to adjust the thickness of the paint, whose minimum could be 0.06mm.

3. The movable curtain head with the best structure, a reasonable use of pneumatic devices, that easy and fast to clean the machine.

4. Paint supply system with the America high power pumps which best to vanish the bubble. Also in thepipeline it is structured profes sionally with the bubble disappearing device. To ensure the uniformity of the paint, no defects; Defoaming powerful, 5 minutes to complete it



MODEL

600#

1000#

1300#

Working width

620mm

920mm

1320mm

Feeding speed

2-60m/min

2-60m/min

2-60m/min

Min length

500mm

500mm

500mm

Working thickness

2-100mm

2-100mm

2-100mm

Feeding power

1.5kw*3

1.5kw*3

1.5kw*3

Heeting power

18kw

18kw

18kw

Coating pump power

2.2kw

2.2kw

2.2kw

Overall dimensions(L*W*H))

12500*1300*1300mm

12500*1700*1300mm

12500*2100*1300mm

Weight

1500kg

1800kg

2000kg
