Strong Stable Structure Wood Coating Machine Easy Cleaning High Productivity


Large Image :  Strong Stable Structure Wood Coating Machine Easy Cleaning High Productivity

Product Details:
Place of Origin: Jiangsu
Brand Name: JINGZHI
Certification: CE
Model Number: JZ-600# JZ-1000# JZ-1300#
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $15000-25000/set
Packaging Details: Standard shipping
Delivery Time: 35-45 working day
Payment Terms: T/T
Supply Ability: 50sets/month
Detailed Product Description
Weight: 1500kg Voltage: 380v Three Phase 50-60HZ
Condition: New Warranty: One Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas Working Speed: 15-25m/min
High Light:

automatic coating machine


lamination coating machine

1. This machine is designed for painting products with deep embossing on SPC floors;

2. The color of the surface after being colored by the machine is more uniform and clear, thereby making up for the lack of uneven embossing of the roller coating, making the surface texture of the plate clearer and the layered three-dimensional sense stronger;

3. The conveyor belt and brush wheel are controlled by frequency converter, reducer and motor;

4. The brush wheel adopts quick-release design, which is convenient for cleaning and disassembly;

5. The conveyor belt can be equipped with vacuum suction device;

6. The machine can be equipped with professional cleaning devices;


A. Function: this machine is suitable for surface coating of all kinds of flat plates (such as board furniture, solid wood composite floor, plastic decorative plate, metal, etc.).

B. Features: the coating wheel, quantitative roller and conveyor belt are all controlled by independent inverter and reducer, so that the smoothness and film thickness of the paint surface can be more accurately controlled.The coating wheel is made of imported rubber material, equipped with high-quality electroplating quantitative rolling and imported stainless steel scraper, the Angle is adjusted by the micro RV gear reducer, the distance between the electric light wheel and the rubber wheel is adjusted by the micro RV gear reducer, the accuracy is accurate.This machine is suitable for all kinds of paint, such as: UV, PU, NC and waterborne paint, paint can be recycled.C. Optional: this machine can be fully automated controlled by PLC microcomputer;Automatic lifting device can be used for lifting.


Model working width working thickness minimum length feeding speed coating roller power doctor roller feeding power L*W*H(MM)
600# 600MM 3-80MM 300MM 0-25M/MIN 0.75KW 0.75KW 0.75KW 1600*2000*1550
1000# 1000MM 3-80MM 300MM 0-25M/MIN 1.5KW 0.75KW 1.5KW 1600*2450*1550
1300# 1300MM 3-80MM 300MM 0-25M/MIN 1.5KW 0.75KW 1.5KW 1600*2750*1550


JINGZHI Machinery Manufacturing Co., Ltd. is located in Huaqiao Industrial Park, Suzhou City. We are an enterprise combining the research, design, development, manufacturing, sales and technical services of painting and printing machinery.


1. Our machinery is widely used in printing and coating the plastic floor, solid wood, composite floor, wallboard, plywood, door board, foaming board, medium and high-density board, calcium silicate board, wood, modular furniture, etc. Our machine applies to UV.PU.NC. Waterborne paint.

2. The machine type: Precision roller coating machine, Precision color brush machine, Putty filling machine, Curtain machine, UV dryer, LED dryer, Hot air dryer, Vacuum spraying machine, Sanding machine, Polishing machine, Jet air dryer.

3. Our company made a number of product patents, some of which had filled a number of gaps in technology in China.

4. Our foreign customers: Iran, Brazil, Japan, USA, Netherlands, Vietnam, Malaysia, Indonesia, Ethiopia, etc.

In accordance with customers' actual production needs, our company provides the most scientific and rigorous production process and equipment for every customer. Our products not only achieve the best effect of painting but also thoroughly solve many production problems, such as environmental pollution, low efficiency & high cost, which are caused by the traditional painting process.
