Specializing in floor production and supporting automation equipment.
| Place of Origin: | China |
|---|---|
| Brand Name: | FLE |
| Certification: | CE |
| Model Number: | 1300# |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiation |
| Packaging Details: | Standard Packing |
| Delivery Time: | 40-60 working days |
| Payment Terms: | T/T L/C |
| Supply Ability: | 50sets/month |
| Dimension: | 26500mm*2500mm*1500mm | Name: | SPC Deep Embossing Coating Machine |
|---|---|---|---|
| Voltage: | 380v Three Phase 50-60HZ | Condition: | New |
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Working Speed: | 15-20m/min | Material: | Steel |
| High Light: | Deep Embossing UV Roller Coating Machine,paint UV Roller Coating Machine,Deep Embossing paint finishing equipment |
||
SPC Deep Embossing Coating Machine
Applications
This production line is aimed at products with very deep SPC floor texture, so that the products texture can be evenly applied to the paint, to avoid the floor embossing too deep, and the paint can not fill the board texture and white bright spots.
Quick Detail
This production line consists of9 machines.
1. The first electrostatic precipitator is used to remove static electricity on the surface of SPC, the second hot air dryer is used to soften the board surface, and the third single roll coater is used to paint the board surface.,The fourth double-headed brush machine is used to apply paint to the texture of the floor, the fifth dual-lamp UV dryer is used for semi-dry paint, and the sixth single-roll coater is used to apply paint to the floor Seven leveling machines are used to eliminate air bubbles and control gloss, the eighth six-lamp dryer is used to completely dry the paint, and the ninth conveyor is used to inspect the floor and receive materials.
Specifications: The whole production line is 26500 mm long, 2500 mm wide and 1500 mm high. The power of the whole machine is 165KW
Competitive Advantage:
We are the best coating manufacturer in China, with a market share of 60% in China. The products are sold to the United States, Brazil, Africa, the Netherlands, South Korea, and India ... Our equipment configuration is very high, and the dryer uses electronic power supply. 25% energy saving, higher energy intensity and faster production speed. The roller coater is very precise, and the surface effect of the product is very good, without horizontal stripes. We have a strong after-sales team, no matter where you are on the earth, we can provide the best service
| model | JZ-1300# |
| Number of machines | 9 |
| Colour mode | white |
| Working width | 1300mm |
| Painting speed | 15-25 meters per minute |
| Heating and drying system | UV lamp |
| Power on | 170KW |
Suzhou FLE international trade Co., Ltd. is located in Suzhou City. We are an enterprise combining the research, design, development, manufacturing, sales and technical services of painting and printing machinery.
1. Our machinery is widely used in printing and coating the plastic floor, solid wood, composite floor, wallboard, plywood, door board, foaming board, medium and high-density board, calcium silicate board, wood, modular furniture, etc. Our machine applies to UV.PU.NC. Waterborne paint.
2. The machine type: Precision roller coating machine, Precision color brush machine, Putty filling machine, Curtain machine, UV dryer, LED dryer, Hot air dryer, Vacuum spraying machine, Sanding machine, Polishing machine, Jet air dryer.
3. Our company made a number of product patents, some of which had filled a number of gaps in technology in China.
4. Our foreign customers: Iran, Brazil, Japan, USA, Netherlands, Vietnam, Malaysia, Indonesia, Ethiopia, etc.
In accordance with customers' actual production needs, our company provides the most scientific and rigorous production process and equipment for every customer. Our products not only achieve the best effect of painting but also thoroughly solve many production problems, such as environmental pollution, low efficiency & high cost, which are caused by the traditional painting process.
